5G NTN NR gNodeB

Deploy and operate 5G New Radio over satellite, starting at the physical layer.

Gatehouse Satcom will deliver a standards-aligned 5G NTN NR gNodeB physical layer for satellite operators, integrators, and technology partners building non-terrestrial 5G networks.

The solution focuses on the hardest part of NTN New Radio – the PHY – enabling realistic demonstrations, early deployment scenarios, and informed architectural decisions in real satellite environments.

Snow-covered weather station on mountain summit with clouds.

From terrestrial assumptions to non-terrestrial reality

5G New Radio was designed for terrestrial networks. When applied to satellite systems, a different set of constraints defines what is feasible in practice.

Non-terrestrial deployments place the highest technical burden on the physical layer. Satellite dynamics, long delays, Doppler effects, spectrum conditions, and payload constraints all surface at PHY level first. Addressing these early is essential for realistic demonstrations and deployment planning.

This is why Gatehouse Satcom focuses its 5G NR NTN offering at the physical layer, enabling customers to progress from analysis to integration with reduced uncertainty.

5G NR NTN

Key deployment considerations

Non-terrestrial 5G deployments introduce practical constraints that must be accounted for early. Gatehouse Satcom supports customers in addressing these topics through a PHY-first approach and deployment-oriented system work.

  • Scientists inspect satellite in a laboratory setting.

    Payload constraints

    Size, weight, power, and processing budgets influence where and how PHY functions can be deployed.

  • Blue concentric rings of light

    Spectrum context

    NTN spectrum usage differs from terrestrial deployments and impacts system configuration and demonstration setups.

  • Earth with lasers and starry sky backdrop

    Beam management

    Satellite beam behaviour, mobility, and coexistence with existing systems require NTN-specific handling.

  • Futuristic digital circuit board background with glowing lines.

    Architecture choices

    Open RAN and functional split options affect integration effort and long-term flexibility.

5G NTN Stack Architecture

Based on 3GPP 5G NR and NTN functional split definitions

The Gatehouse Satcom NR gNodeB PHY is designed as a modular component within a broader non-terrestrial 5G architecture. It implements the NR physical layer adapted for satellite conditions and interfaces seamlessly with Layer 2 and Layer 3 components as part of an integrated NTN stack.

Gatehouse Satcom delivers the NR gNodeB PHY as a core technology component while integrating higher-layer functions through established ecosystem partnerships, enabling a complete and deployment-ready solution without constraining architectural flexibility.

The architecture supports realistic deployment scenarios, where the PHY connects to real or emulated satellite links, terminals, and core network components. This makes it suited for demonstrations, feasibility studies, and early operational environments.

By separating PHY responsibilities from higher-layer functions, teams can evaluate NR behaviour over satellite, assess system trade-offs, and evolve toward full-stack implementations as standards and programme maturity progress.

Discuss your integration requirements

We help teams identify the right split point and integration path for their programme.

Talk to our engineers
Integrated partner stack
Gatehouse Satcom - NR gNodeB PHY
5GC

Core Network

AMF, SMF, UPF and associated control-plane functions. Handles authentication, session management and mobility via the NG interface towards the RAN. Deployed on-ground in both transparent and regenerative NTN architectures.

L3

Layer 3 - RRC / PDCP

Radio Resource Control and Packet Data Convergence Protocol. Handles radio bearer setup, control-plane signalling and PDCP functions such as header compression and ciphering. Supports NTN-specific configuration including timing-advance pre-compensation for long propagation delays.

L2

Layer 2 - MAC

Medium Access Control scheduling and HARQ management. Adapted for NTN's extended round-trip time, supporting configurable HARQ disable and extended DRX cycles to accommodate GEO/MEO/LEO delay budgets.

Split 6 - PHY / MAC boundary
Hi-PHY

High-PHY

Channel coding (LDPC / Polar), rate matching, scrambling, modulation mapping (QPSK → 256-QAM), and HARQ processing. Split 6 defines the PHY/MAC boundary. This split allows the full PHY to be optimized for satellite impairments, while MAC and higher layers can be integrated with external RAN components.

Split 7.2 - High-PHY / Low-PHY boundary
Lo-PHY

Low-PHY

FFT/IFFT, resource element mapping, OFDM symbol generation, cyclic-prefix insertion, and digital front-end processing. Split 7.2 is the most common Open RAN fronthaul split, but can be challenging in NTN deployments due to fronthaul timing constraints, particularly over long satellite links.

Split 8 - Full PHY / RF boundary
R.U.

Radio Unit

Analogue RF front-end — DAC/ADC conversion, up/down-conversion, power amplification, and antenna array control. The RU interfaces digitally with the DU via eCPRI or DIFI (VITA 49) over the fronthaul link, converting between the digital domain and the analogue RF signal chain. Split 8 is the traditional full-PHY/RF boundary: the entire Layer 1 is centralized (on ground or onboard a regenerative payload) with no disaggregation inside the PHY. Simplest architecture for early NTN deployments.
